American Made, Iron Clad Protected - Discover the Industries Best Warranty.
Steel Guard manufactures clear plastic curtain wall systems with high-quality PVC to ensure that workspaces, businesses and even homes are protected. Clear curtains are custom made to suite all indoor and outdoor applications. Made to your exact dimensions, and quick shipped for a fast install. The clear PVC curtains are used inside warehouses, manufacturing facilities, and even as wide a range of uses as offices, shops, and porches. All PVC plastic materials are waterproof and provide protection against chemicals, bacteria, and outdoor elements. The 20mil clear plastic is ideal for inside applications and 40mil clear with reinforcement is ideal for outdoor applications.
Benefits of Clear Industrial Curtains
Steel Guard’s New Sneeze Shield Portable Sneeze Guards are perfect for easily mounting on counters or table tops to stop the spread of harmful bacteria and Coronavirus. Our Clear Floor Standing Screens can be used to separate work areas in commercial, industrial applications, or Anywhere Space Dividing & Social Distancing is needed. Standard and Custom Sizes available. See links below for more info.
Have a specific industrial application that needs a custom curtain solution? Are run-of-the-mill curtain fabrics unable to effectively guard your work area? A typical pvc curtain wall cannot properly guard many specialty applications in high heat, light blockage, humidity, or chemical protection. If your in this type of situation, you may need a custom manufactured and designed solution to solve your problem. Steel Guard Can Also use Opaque Vinyl and Clear Vinyl Materials in Combination, to create the precise curtain for your application.
Steel Guard’s long-standing knowledge of industrial curtain and barrier applications encompasses hundreds of different applications and technical fabric types, giving you accessibility to create a custom solution for your application. Some custom add-ons include:
2-Wheel Nylon Roller Hooks
Make sliding and folding of the curtain a cinch. 2-wheel steel roller hooks are available for tall curtain systems.
#2 Toothed Brass Grommets
#2 Brass Toothed Grommets are spaced every 12 in. on center of the curtains to hang securely on the roller hooks.
Galvanized Steel Roller Track
Heavy-Duty 16 gage roller track system which modularly connects track lengths to your desired length and shape. (Dim – O.D. – H-1.25″ x W-1.44″)
Track Mounting Hardware
5 Different Mounting Options Available. Including a Universal Mount to use in place for Beam to Chain, Threaded Rod, and Wall Mount. (See Mounting & Hardware)
Velcro Attachments
2 in. Velcro side attachments easily seal and attach both sides of curtains to multiple curtains. Available in standard 2ft x 1ft swatches, full length, or custom.
Chain Weighted Hem
Heavy-Duty 3/16 in Thick Galvanized Chain inserted into the bottom pocket to stabilize the curtain against wind & drafts.
Heat Welded Interior Seams
Interior Seams are Electronically welded with RF Bar Sealers for an Extra tough resistance to tears. Outer Hems are sewn with a heavy-duty double-lock stitched nylon thread.
Vinyl Floor Sweep
Vinyl Floor Sweep – Sewn-on or Velcro Option – Seals bottom 1″ gap to seal off dust, dirt, & contaminants.
Part# CA 300 – Sewn On<br>Part# CA 299 – Velcro
Floor Mount D Ring Attachments (Add-On)
Floor Mount D-Rings – Included with strap and buckle. Fastens the curtain to the floor protecting against wind & updrafts
Part# CA 101
Adhesive Velcro (Add-On)
2 inch Adhesive Velcro – Attaches any curtain to a brick, metal, concrete, or wood wall or door opening.
Part# CA 677 – 2″ PSA Loop
Part# CA 694 – 2″ PSA Hook
Strip Curtain Walk-Drive Through
Equip your curtain with the flexibility to walk or drive through without opening your entire system. Can be equipped for Man or Forklift Traffic
Part# CA 900
Magnet Attachments (Add-On
2 in. Magnets Attachments provide a quick and easy attaching and un-attaching of multiple curtains.
Part # CA 550 – Sew On
Part # CA 551 – Adhesive PSA
20 Mil Clear PVC FR - Transparent
Completely Transparent PVC Vinyl Material. 20 Mil Thick or .020 inches. Double Polished for a smooth finish and completely clear viewing. Our most popular PVC Material. The Vinyl Meets Flame Resistant Standards, CFM, NFPA-701 & ASTM E-84. For Tech Specs see 20 mil clear PVC FR Technical Specifications
20 Mil Clear PVC - FR
40 Mil Clear PVC FR - Transparent
Completely Transparent PVC Vinyl Material. 40 Mil Thick or .040 inches. Double Polished for a smooth finish and completely clear viewing. A thicker PVC Curtain Material for Heavier Duty Applications. The Vinyl Meets Flame Resistant Standards, CFM, NFPA-701 & ASTM E-84. For Tech Specs see 40 mil clear PVC FR Technical Specifications
40 MIl Clear PVC - FR
Track System is mounted in from beams or trusses with a C-Clamp, and using a 3/8″ Threaded Rod to suspend down to the desired height. The Threaded Rod Track Mounts then slide over the threaded rod. Mount Spacing can be from 4′ -8′ with taller heavier systems over 25′ being 6′ or less usually
TH C600
TH C502
TH C503
TH C601
TH C604 Use w/ 500s
TH C900 - Sub for Threaded Rod, Beam to Chain, & Wall
Track System is mounted in from beams or trusses with a C-Clamp, and using an S-Hook suspended down with chain to the desired height. The Track Mounts then connect the system with more S-hooks. Aircraft Cable is another option to use instead of chain. Mount Spacing can be from 4′ -8′ with taller heavier systems over 25′ being 6′ or less usually
TH C500
TH C501
TH C503
TH C501
Ceiling Mount Hardware is attached with lag bolts directly flush to ceiling, floor joists or to steel beams.
TH C200
TH C202
TH C203
TH C201
For the Wall Mount installation method, track mounts are attached to walls above openings, or you can use wall end brackets to brace or stabilize the track.
TH C303
TH C302
TH C301
TH C300
The Floor Mount System which is Free Standing, uses base plates at intervals anywhere from 4′ – 10′ depending on the height of the curtain system. The base plates attach to posts which connect to the floor mount splices.
TH C800
TH C802
TH C803
TH C801
6' - TH F06, 7' - TH F07
8' - TH F08, 9' - TH F09
10' - TH F10, 12' - TH F12
TH C804
Straight Tracks, Plain Connectors, Universal Mounts, End Stops, as Well as Pulleys to Customize Your Track Curtain System.
TH R101
TH R100
TH C700
4' - TH T04
5' - TH T05
6' - TH T06
7' - TH T07
8' - TH T08
10' - TH T10
12' - TH T12
