Construction Sound Barriers

Steel Guard Manufactures a Variety of Construction Sound Barriers for Heavy Construction Sites that absorb and block sound. These Sound Curtains are made to adhere to Walls or Fences on construction sites. The blankets are considered “Temporary”, but will stand up for outdoor use for several years. These Sound Barriers are made of 1”, 2” or even 4” Quilted Fiberglass, with the option to add Mass Loaded Vinyl backing to block unwanted noise pollution into areas outside of the site.

Benefits of Sound Shield™ Construction Sound Barriers

  • Stops Noise Pollution From Demolition, Digging, Compressors, Jack Hammers & More.
  • Keeps Communication, and Speech Levels Intelligible, making Workers Tasks, Leaner and More Efficient.
  • Keeps OSHA Safe Noise Levels for your Construction Crew, as well as Noise Levels for Adjacent Residential or Commercial Public Areas.
  • Can be Custom Designed to Adhere to Fences with Not Just Grommets, but Straps, Velcro, & More.

FOR MORE INFORMATION ON SOUND ATTENUATION SPECS SEE MATERIALS TAB

Additional Information:

Types of Construction Noise Barriers

  • SCC-9 EXT – 2″ Fiberglass Batting with Outdoor Rated Vinyl Quilted Face Front & Back- NRC-.85, STC-19 – See More Details
  • SCC-12 EXT -1″ Fiberglass Batting with Outdoor Rated Vinyl Quilted Face Front & 1 lb sq/ft Reinforce Mass Loaded Vinyl Back – NRC -.70, STC 27 – See More Details
  • SCC-13 EXT -1″ Fiberglass Batting with Outdoor Rated Vinyl Quilted Face Front & 1 lb sq/ft Reinforce Mass Loaded Vinyl Back – NRC – .85, STC 32 – See More Details

For more information on designing your Temporary Sound Barrier Wall, or do get a quote, contact one of our Experienced Sales Staff at 1-800-347-8368

Construction Sound Barrier Materials

2" Silicone Coated Vinyl Front and Back Quilted on FiberglassNRC .75STC 29

2" Silicone Coated Vinyl Front and Back Quilted on Fiberglass
NRC .75
STC 29

Front - 1" Silicone Coated Vinyl Quilted Fiberglass + Interior - 1 lb/sq ft Mass Loaded Vinyl + Back - 1" Vinyl Quilted FiberglassNRC .70STC 27

Front - 1" Silicone Coated Vinyl Quilted Fiberglass + Interior - 1 lb/sq ft Mass Loaded Vinyl + Back - 1" Vinyl Quilted Fiberglass
NRC .70
STC 27

Front - 2" Silicone Coated Vinyl Quilted Fiberglass + Interior - 1 lb/sq ft Mass Loaded Vinyl + Back - 1" Vinyl Quilted FiberglassNRC .85STC 32

Front - 2" Silicone Coated Vinyl Quilted Fiberglass + Interior - 1 lb/sq ft Mass Loaded Vinyl + Back - 1" Vinyl Quilted Fiberglass
NRC .85
STC 32

SCC-9 EXT, SCC-12 EXT, SCC-13 EXT

SOUND ABSORPTION (HZ) PER ASTM C423

Model Number 125 250 500 1000 2000 4000 NRC
SCC-9 EXT .19 .99 .96 .80 .57 .33 .85

SOUND TRANSMISSION LOSS (HZ) PER ASTM E90-75

Model Number 125 250 500 1000 2000 4000 STC
SCC-9 EXT 6 11 15 20 25 32 19*



SOUND ABSORPTION (HZ) PER ASTM C423

Model Number Thickness 125 250 500 1000 2000 4000 NRC
SCC-12 EXT 1″ 0.12 0.47 0.85 0.84 0.64 0.62 0.70
SCC-13 EXT 2″ 0.07 0.27 0.96 1.13 1.08 .99 .85

SOUND BLOCKING PERFORMANCE (HZ)

Model Number Thickness 125 250 500 1000 2000 4000 STC
SCC-12 EXT 1″ 11 16 24 30 35 35 27
SSC-13 EXT 2″ 13 20 29 40 50 55 32
